- Código RS:
- 181-7573
- Nº ref. fabric.:
- CY62128EV30LL-45ZXI
- Fabricante:
- Cypress Semiconductor
Temporalmente fuera de stock. El producto se entregará cuando vuelva a estar disponible.
Añadido
Precio unitario (Suministrado en múltiplos de 4)
1,035 €
(exc. IVA)
1,252 €
(inc.IVA)
Unidades | Por unidad | Por Pack* |
4 + | 1,035 € | 4,14 € |
*precio indicativo |
- Código RS:
- 181-7573
- Nº ref. fabric.:
- CY62128EV30LL-45ZXI
- Fabricante:
- Cypress Semiconductor
Documentación Técnica
Legislación y Conformidad
Estado RoHS: No aplica
Datos del Producto
Very high speed: 45 ns
Temperature ranges:
Industrial: –40 °C to +85 °C
Wide voltage range: 2.2 V to 3.6 V
Pin compatible with CY62128DV30
Ultra low standby power
Typical standby current: 1 μA
Maximum standby current: 4 μA
Ultra low active power
Typical active current: 1.3 mA at f = 1 MHz
Easy memory expansion with CE1, CE2,and OE features
Automatic power-down when deselected
Complementary metal oxide semiconductor (CMOS) for optimum speed and power
Offered in Pb-free 32-pin small outline integrated circuit (SOIC),32-pin thin small outline package (TSOP) Type I, and 32-pin shrunk thin small outline package (STSOP) packages
Temperature ranges:
Industrial: –40 °C to +85 °C
Wide voltage range: 2.2 V to 3.6 V
Pin compatible with CY62128DV30
Ultra low standby power
Typical standby current: 1 μA
Maximum standby current: 4 μA
Ultra low active power
Typical active current: 1.3 mA at f = 1 MHz
Easy memory expansion with CE1, CE2,and OE features
Automatic power-down when deselected
Complementary metal oxide semiconductor (CMOS) for optimum speed and power
Offered in Pb-free 32-pin small outline integrated circuit (SOIC),32-pin thin small outline package (TSOP) Type I, and 32-pin shrunk thin small outline package (STSOP) packages
Especificaciones
Atributo | Valor |
---|---|
Tamaño de la Memoria | 1Mbit |
Organización | 128k x 8 bits |
Número de Palabras | 128k |
Número de Bits de Palabra | 8bit |
Tiempo de Acceso Aleatorio Máximo | 45ns |
Ancho del Bus de Direcciones | 8bit |
Baja Potencia | Sí |
Tipo de Montaje | Montaje superficial |
Tipo de Encapsulado | TSOP |
Conteo de Pines | 32 |
Dimensiones | 18.3 x 8.2 x 1.05mm |
Altura | 1.05mm |
Tensión de Alimentación Máxima de Funcionamiento | 3.6 V |
Tensión de Alimentación de Funcionamiento Mínima | 2.2 V |
Temperatura de Funcionamiento Mínima | -40 °C |
Ancho | 8.2mm |
Temperatura Máxima de Funcionamiento | +85 °C |
Longitud | 18.3mm |
- Código RS:
- 181-7573
- Nº ref. fabric.:
- CY62128EV30LL-45ZXI
- Fabricante:
- Cypress Semiconductor
